Scylla SH10shr
Our SH10SHR is the word's fastest sevo valve at less than 2m step response and a frequency response of 750 Hz. Need top speed for your demanding applications? This is your winner.
Product Description
Step response: <2ms • Frequency response: >750 Hz (25% Signal) • Hysteresis: <0.1% • Leakage: <2% x Qn
Rated flow: 5 - 80 l/min • Size: NG6 (CETOP 5) • Weight: 6kg • Input signal: ±10V, ±10mA, 4..20mA
Supply voltage: 22..30V • P,A,B: <350bar, T: <100bar, max flow 90 l/min
Applications
Die Casting
Metal Processing
Presses
Injection Moulding
Simulation & Test
