Scylla SH7lc
The G761 Challenger. This ultra-fast direct drive servo valve is the ideal drop-replacement for any Moog G761, offering faster speeds at more reasonable cost, with significantly higher contamination resistance and a performance independent of supply pressure. Since there is no quiescent leakage flow, this valve will save you hundreds of dollars over its lifetime.
Product Description
Step response: <3.5ms • Frequency response: >200 Hz (25% Signal) • Hysteresis: <1.0% • Leakage: <0.8%
Rated flow: 5 - 60 l/min • Size: ISO 10372-04-04-0-92 • Weight: 0.8kg • Input signal: ±10V, ±40mA
Supply voltage: 22..30V • P,A,B: <350bar, T: <100bar, max flow 90 l/min
Applications
Power Gen
Metal Processing
Presses
Wood
Simulation & Test
