Scylla SH3lc

Scylla's miniature direct drive servo valve:

Unparalleled in speed and accuracy, weighing only 204g, making it the lightest, fastest and most compact servo valve on the market in its class.

Product Description

Step response: 2.5ms • Frequency response: >130 Hz (25% Signal) • Hysteresis: <1% • Leakage: <1.5%

Rated flow: 5 / 7 / 10 / 15 l/min • Size: S01 • Weight: 204g • Input signal: ±10V, ±10mA, ±20mA, 4-20mA

Dimensions: 42 x 42.2 x 42.9 mm • Supply voltage: 22..30V • P,A,B: <350bar, T: <100bar

Applications

Animatronics

Robotics

Motorsport

Aerospace

Simulation & Test

Request Quote Download Datasheet
