Scylla SH7lc-A

Our ultra-compact and fast direct NG6 valve offers all of the benefits of direct drive, such as high chip-shear and robustness, with none of the downsides: dynamic properties, package size beat any valve in this flow category (40 l/min).

Product Description

Step response: <3.5ms • Frequency response: >200 Hz (25% Signal) • Hysteresis: <1.0% • Leakage: <0.8%

Rated flow: 5 - 50 l/min • Size: NG6 (CETOP 3) • Weight: 0.51kg • Input signal: ±10V, ±40mA

Supply voltage: 22..30V • P,A,B: <350bar, T: <100bar, max power draw: 3W

Applications

Injection Moulding

Motorsport

Power Gen

Aerospace

Simulation & Test
